Frame C:62® Monocoque Advanced Twin Mold Technology,
Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile
Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal
Cable Routing
Fork SR Suntour Aion 38X 2CR Air, Tapered, 15x110mm,
Lockout, 170mm
Shock SR Suntour TRIAir 2CR 230x65mm
Motor Bosch Drive Unit Performance Line CX max. 100Nm
(BDU38)
Battery Bosch PowerTube 800
Front brake Magura Louise, Front 4-Piston/Rear
4-Piston, Hydr. Disc Brake (203/203)
Rear brake Magura Louise, Front 4-Piston/Rear
4-Piston, Hydr. Disc Brake (203/203)
Rear derailleur Shimano XT RD-M8100-SGS, ShadowPlus,
12-Speed
Shifters Shimano Deore SL-M6100, Rapidfire-Plus
Crankset Acid MTB Hybrid Pro, 36T
Cassette Shimano Deore CS-M6100, 10-51T
Chain KMC e12
Headset Acros AZF-675, ICR (Integrated Cable
Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2"
(ZS 56mm), Fiber Inserts for Angle Adjustment, X-Connect Interface
Handlebar Cube Rise Trail Bar 35
Stem Cube Performance Stem E-MTB 35, FPI-Link
Handlebar tape/Grips Acid Disrupt, Soft Compound
Wheels Acid SLX 30, 32/32 Spokes, 15x110mm/12x148mm,
Tubeless Ready
Tyre Schwalbe Magic Mary, Performance, 2.4
Saddle Acid Venec EMTB Trail 140
Seatpost Cube Dropper Post, Handlebar Lever, Internal
Cable Routing, 31.6mm
Seatpost clamp Cube Semi-Integrated
Pedals Acid PP MTB
