The Stereo Hybrid ONE77 HPC SLT leaves nothing on the table in its pursuit of big-mountain riding perfection. The mullet wheelset is built around a pair of Newmen Phase 30 carbon wheels, shod with Schwalbe's tough and tenaciously grippy Magic Mary and Albert 2.5in tyres. That's a good thing, because the Magura Race Pro hydraulic disc brakes need all the traction they can get to deliver their safe, predictable stopping power. There's a remote dropper seatpost, of course. Sram's XX Eagle Transmission 1x12 gears are driven via a Race Face Era carbon crank – and assistance from Bosch's most powerful CX-R drive and 800Wh PowerTube battery – for quick, precise electronic shifts. With Fox's 38 Factory Grip X2 fork and Float X2 Factory shock delivering 170mm of plush, well-controlled travel at each wheel, it's safe to say that the rest comes down to you. Are you up for it?
Frame
The Stereo Hybrid ONE77 HPC frame – with 170mm travel front and rear and a mullet wheel set-up with 29in front and 27.5in rear – is all you need for big days out on big mountain trails. We added Internal Cable Routing for super-clean looks, and then threw in an angle-adjustable headset so that you can tweak the handling to your taste. The 800Wh PowerTube battery sits unobtrusively in the carbon down tube, just above the Bosch CX-R drive. A UDH dropout on the aluminium rear triangle is tough and future-proof, and we also included a Direct Mount chain guide to keep you driving forwards even when the going gets rough.
Specification
| Frame | C:62® Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing |
|---|---|
| Fork | Fox 38 Float Factory GRIPX2, Tapered, 15x110mm, E-Bike Optimized, 170mm |
| Frame shock | Fox Float X2 Factory, 230x65mm, High/Low Speed Rebound & Compression w/ 2-Position Lever, Kashima Coated |
| Shock hardware | Front: 30x8mm, Rear: DU-Bushing 12.7mm |
| Headset | ACROS AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), Fiber Inserts for Angle Adjustment, X-Connect Interface |
| Stem | CUBE Performance Stem E-MTB 35, FPI-Link |
| Handlebar | Race Face ERA 35 |
| Grips | ACID Endure |
| Rear Derailleur | Sram XX Eagle AXS™ Transmission, 12-Speed |
| Chain Guide | Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate |
| Shifters | Sram AXS™ Pod Ultimate Controller |
| Brakes | Magura Race PRO, Front 4-Piston/Rear 4-Piston, Hydr. Disc Brake (203/203) |
| Crankset | Race Face ERA E-MTB, 36T |
| Cassette | Sram XS-1297, 10-52T |
| Chain | Sram XX Eagle Transmission |
| Wheelset | Newmen Phase 30 base/strong, 28/28 Spokes, 15x110mm / 12x148mm, Tubeless Ready |
| Tires Front | Schwalbe Magic Mary Trail Pro, Addix Soft, Kevlar, 2.5 |
| Tires Rear | Schwalbe Albert Gravity Pro, Addix Soft, Kevlar, 2.5 |
| Pedals | ACID PP Rookie large |
| Saddle | ACID Venec EMTB Trail 140 |
| Seatpost | Fox Transfer Factory 31.6mm, Kashima Coated |
| Seatpost clamp | CUBE Semi-Integrated |
| Motor | Bosch Drive Unit Performance Line CX-R max. 120Nm (BDU38) |
| Battery | Bosch PowerTube 800 |
| Charger | Bosch 4A |
| Remote | Bosch Mini Remote |
| Display | Bosch Kiox 400C |
| Weight | 23,5 kg |
| System Weight max. | 160 kg |
| Driver max. Weight | 125 kg |
