Frame 6061 aluminium tubing, double butted and technoformed. BSA BB standard, 9mm QR axle standard. Replaceable dropout.
Max tyre size 24" x 2.4"
Fork aluminium
Gears 8
Shifter Rear Microshift Acolyte Quick Trigger Pro; SL-M6285-R; Super short reach; Gear indicator
Rear Derailleur Microshift Acolyte Speed Super Short Cage; RD-M5180S; Super short cage
Bottom Bracket Squared LL116
Chain KMC Z8.3
Chainset Prowheel A10PP; 32 tooth chainset; material: aluminium;
Crank length 127mm
Cassette Microshift CS-083; 11-38 teeth; 8 speed
Front Brake Tektro HD-J2820; hydraulic Disc brake; short reach with Tektro TR160-52; 160mm
Rear BrakeTektro HD-J2820; hydraulic Disc brake; short reach with Tektro TR160-52; 160mm
Grip Merida Expert JR
Handlebar Merida Expert JR; material: aluminium; 600mm wide; 25mm rise
Stem Merida Comp CC; material: aluminium; 31.8 mm diameter; 7 degree rise
Head Set FSA NO.10P Neck15
Pedal VP VPE-229
Saddle Merida Expert JR
Seat Post Merida Comp CC; 27.2mm diameter; in-line; material: aluminium
Wheel Size 24"
Rims Merida JR 24+; material: aluminium
Spokes Black steel
Front Hub KT-K68F; 100x9mm; 24 Spoke
Rear Hub KT-K68R-8/9/10S; 135x9mm; 24 Spoke
Front Tyre Maxxis Pace; 24x2.10"; wired
Rear Tyre Maxxis Pace; 24x2.10"; wired
Colour Evergreen (Turquoise/Black)
Kickstand adjustable alloy
