Frame Amflow PL Carbon Frame, Satin Silver, 150mm rear travel, Compatible with 27.5" and 29" rear wheels
E-Bike System Avinox Ml Drive Unit: 105 Nm, Avinox Screen: 2-inch OLED Control Display, Avinox Integrated Battery: 800Wh, Avinox Wireless Controllers: Right and left sides, Avinox Fast Charger: 12A/508W
Fork 2026 FOX 36 Performance, 160mm travel, GRIP Damper, 15x110mm, 44mm rake
Rear shock 2026 FOX Float Performance, Trunnion (185×55mm), custom tune, EVOL Air sleeve, 2-position lever
Transmission
Rear Derailleur SRAM Eagle 70 Transmission Derailleur
Chainring SRAM Eagle Transmission E-MTB Chainring 104BCD 34T
Shift Levers SRAM Eagle 70 Transmission Shifter | Single Click
Cassette SRAM XS-1270 Eagle Transmission 10-52T
Chain SRAM Eagle 70 Transmission Flattop Chain
Crankset Avinox SL Crank (м/L: 155mm; XL/XXL: 160mm)
Brakes Magura MT5 hydraulic disc brake, HC lever, 4-piston caliper w/ Shiftmix 3, 203mm MDR-C Rotor (front and rear)
Wheels Amflow HMA-30 Rims: Alloy, 29", 30mm internal width, 32H, tubeless ready
Spokes SAPIM E-Light J-bend
Front Hub Alloy, 2 sealed cartridge bearings, 15×110mm thru-axle, 32h, 6-bolt
Rear Hub Alloy, 4 sealed cartridge bearings, 148×12mm thru-axle, 32h, 6-bolt, 21T
Tyres
Front Maxis Assegai MaxTerra 29×2.5" WT 3C EXO E-25 TLR
Rear Maxxis Dissector MaxxTerra 29×2.4" WT 3C EXO+ E-25 TLR
Handlebar Amflow Enduro Alloy Handlebar 35mm rise, 800mm wide 5-degree upsweep, 9-degree backsweep
Grips Amflow Enduro Grips
Stem Amflow Enduro Stem, One-piece CNC Length: 35mm Clamping diameter: 35mm
Saddle Selle Royal SRX Plus
Seatpost KS Rage-i
M: 150mm
L: 170mm
XL/XXL: 190mm
Accessories Quick Start Guide, Torque Wrench (3~25 Nim, Hex 2/3/4/5/6mm, Torx® 25), Shock Pump, Front and Rear Lights
