SPECIFICATIONS

WEIGHT: 22.8 kg (50.3 lb)

FRAME - Tern Quick Haul, Patented Design, 6061-AL, EFBE Tri-Test approved: 150 kg

FORK - Cargo, steel, EFBE approved: 150 kg

STEM - Speedlifter, 150 mm extension, 3D Forged stem, 31.8

HEADSET - TH, cartridge bearings

HANDLEBAR - Low riser, 31.8, 6061-AL

GRIPS/BAR TAPE - Velo ergonomic, lock-on

SADDLE - Velo Comfort

SEATPOST - 6 mm, 6061-AL, micro-adjust clamp

SEATPOST CLAMP - Tern Collar

 FRONT BRAKE - Shimano, hydraulic disc

REAR BRAKE - Shimano, hydraulic disc

BRAKE LEVERS - Shimano, hydraulic disc

BRAKE CABLE & HOUSING - Shimano, hydraulic disc

FRONT HUB - Shimano disc

REAR HUB - Shimano disc

SPOKES AND NIPPLES - Stainless steel

RIMS - Kinetix Comp, for disc

TYRES - Schwalbe Big Apple, 55-406, puncture protection, Reflex

SHIFTER(S) - Shimano Altus, 1 x 8 spd, trigger

REAR DERAILLEUR - Shimano Altus Shadow

CRANKSET - Tern custom, forged 6061-AL crankarm

CASSETTE - Shimano 11-34T, 8 spd

BOTTOM BRACKET - Motor integrated

CHAIN - KMC for eBike, 8 spd

PEDALS - Urban with non-slip surface

MOTOR - Bosch Active Line Plus, 270% Assist, 50 Nm Torque

BATTERY - Bosch PowerPack 400

DISPLAY - Bosch Purion

CHARGER - Compact Charger, 100-240V, 2A

CHAINGUARD - SKS Chainblade

KICKSTAND - Pletscher design, rear mount

LUGGAGE SOCKET - Combo Mount

FRONT LIGHT - Herrmans, 120 lumens

REAR LIGHT - Herrmans

FENDERS - Chromeplastic, stainless hardware

RACK(S) - Atlas Q Rack, UpperDeck Mount System, Vertical Parking, 50 kg capacity

FRAME SIZES:One size

DISTANCE: SEATPOST TO HANDLEBAR:60 - 64 cm (23.6 - 25.2 in)

DISTANCE: SADDLE TO PEDAL:68 - 110 cm (26.8 - 43.3 in)

SUGGESTED RIDER HEIGHT:160 - 195 cm (63 - 76.8 in)

MAX GROSS VEHICLE WEIGHT:150 kg (330.7 lb)

MAX RIDER WEIGHT:120 kg (264.6 lb)

What Makes it a D8?

• Bosch Active Line Plus motor provides up to 50 Nm of torque and 270% support
• 1x8-speed Shimano Altus groupset with trigger shifter

Quick Haul Highlights

• Cargo capacity: 50 kg on the rear rack, plus an additional 20 kg with optional front rack
• Fits riders 160 - 195 cm (5’3” - 6’5”), and also riders 145 - 180 cm (4’9” - 5'11") when equipped with a shorter, 350 mm seatpost
• Lots of available kid- and cargo-carrying accessories—easily create your perfect setup
• Ultra-low 490 mm standover height makes (dis)mounting and waiting at stops easier
• Shimano hydraulic disc brakes for reliable stopping power—even when heavily loaded and riding fast
• Proven safe and reliable: frame and fork are EFBE-tested up to the 150 kg (331 lb) Maximum Gross Vehicle Weight
