Frame Lite Aluminium, endurance geometry. Internal cable routing, 142 x12mm axle standard, BB86, flat mount rear brakes, 1 1/2" headtube.
Max tyre 35c (32c with mudguards)
Fork Scultura Endurance CF3 Disc; full carbon, tapered steerer. Disc Cooler
Gears 24
Shifters Shimano Tiagra
Front Derailleur Shimano Tiagra
Rear Derailleur Shimano Tiagra; GS
Bottom Bracket SM-BB71-41B, Pressfit 86.5
Chain KMC X10
Chainset Shimano Tiagra; 50-34 tooth chainset;
Crank length 165mm (XXS), 170mm (XS), 172.5mm (S/M/L), 175mm (XL)
Cassette Shimano CS-HG500; 12-28 teeth; 10 speed
Brake Lever Shimano Tiagra
Front Brake Shimano Tiagra; Hydraulic disc brake caliper with Shimano RT10; 160mm rotor
Rear Brake Shimano Tiagra; Hydraulic disc brake caliper with Shimano RT10; 160mm rotor
Grip Merida Expert
Handlebar Merida Expert SLII; aluminium; 380mm (XXS-XS-S), 400mm (M-L), 420mm (XL)
Stem Merida Team CC III; aluminium; 31.8mm diameter; -6 degree rise - Length - 90mm (XXS-XS-S), 100mm (M), 110mm (L-XL)
Head Set 320.52.631
Saddle Merida Comp SL; V-mount - made with 25% recycled material
Seat Post Merida Comp CC; 27.2mm diameter; 5 mm layback; Aluminium;
Wheel Size 700c
Rims Merida Expert SLII; 23mm inner rim width; 25mm rim depth; aluminium; Tubeless ready (tubeless tape and valves not included)
Spokes Black stainless
Front Hub JY D981SB; 100 x 12mm; 28 spoke; Centerlock
Rear Hub JY D872SB; 142 x 12mm; 28 spoke; Centerlock
Front Tyre Maxxis Detonator; 700 x 32C; Kevlar bead
Rear Tyre Maxxis Detonator; 700 x 32C; Kevlar bead
Colour Silk Green/Green-Silver
