Frame - Lite II - 6066 triple butted hydroformed aluminium.
Internal cable routing. Tapered head tube, inboard disc mount, BSA BB standard,
135 x 9mm QR axle. Mounts for rack, mudguards and kickstand. Max tyre size 700
x 35c (700 x 32c with mudguard)

Fork - Speeder CF2; Full carbon, tapered steerer, 100 x 9mm
QR standard, Max tyre size: 700 x 35c (700 x 32c with mudguard)

Gears - 18

Shifters - Shimano SL-R3000

Front Derailleur - Shimano Sora

Rear Derailleur - Shimano Sora; SS

Bottom Bracket - FSA TH-7420ST, Cartridge Bearing

Chain - KMC M99

Chainset - FSA Tempo; 50-34 tooth chainset. Crank length:
170mm (XS,S/M), 175mm (L,XL)

Cassette - Shimano CS-HG200; 11-32 teeth; 9 speed

Brake Lever - Tektro
HD-M275

Front Brake - Tektro HD-M275 2 piston hydraulic disc brake
caliper with Shimano RT10 160 mm rotor

Rear Brake - Tektro HD-M275 2 piston hydraulic disc brake
caliper with Shimano RT10 160mm rotor

Grip - Merida Comp EC

Handlebar - Merida Comp TK; aluminium; 600mm wide; Flat

Stem - Merida Comp CC; aluminium; 31.8mm diameter; 6 degree
rise - Stem length: 80mm (XS), 90mm (S), 100mm (SM/ML), 110mm (L/XL)

Head Set - Merida M2331 Neck

Pedal - VP Components, VPE-891

Saddle - Merida Comp SL with V-mount

Seat Post - Merida Comp CC; aluminium; 30.9mm diameter; 5mm
lay back

Wheel Size - 700c

Rims - Merida Comp SL; 17mm inner rim width; 22mm rim depth;
aluminium

Spokes - Black stainless

Front Hub - Joytech D471SBT-SC-CL; 100x9mm; 28 spokes;
Center lock; Quick Release

Rear Hub - Shimano TX505; 135x9mm; 32 spokes; Center lock;
Quick Release

Front Tyre - Maxxis Detonator; 700 x 32C; wire bead

Rear Tyre - Maxxis Detonator; 700 x 32C; wire bead

Colour - Red/Black

• Sporty, comfort oriented geometry
• Lightweight aluminium frame
• Carbon fork with tapered steerer
• Shimano Sora 2 x 9 drivetrain
• Hydraulic disc brakes
