Frame C:62® Monocoque Advanced Twin Mold Technology,
Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing
Fork Fox 36 Float AWL HD Sport RAIL 2.0 R, Tapered,
15x110mm, E-Bike Optimized, 150mm
Shock Fox Float Rhythm R, 230x60mm (27.5: 210x55mm),
Adjustable LSR
Motor Bosch Drive Unit Performance Line CX max. 100Nm
(BDU38)
Battery Bosch PowerTube 800
Display Bosch Purion 400
Front brake Shimano BR-MT420, Hydr. Disc Brake (203/203)
Rear brake Shimano BR-MT420, Hydr. Disc Brake (203/203)
Rear derailleur Shimano XT RD-M8100-SGS, ShadowPlus,
12-Speed
Shifters Shimano Deore SL-M6100-IR, Direct Attach,
Rapidfire-Plus
Crankset Acid MTB Hybrid Pro, 27.5: 36T // 29: 34T
Cassette Shimano Deore CS-M6100, 10-51T
Chain KMC e12
Headset Acros AZF-675, ICR (Integrated Cable Routing), Top
Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), Fiber Inserts for Angle Adjustment, X-Connect Interface
Handlebar Cube Rise Trail Bar 35
Stem Cube Performance Stem E-MTB 35, FPI-Link
Handlebar tape/Grips Acid Disrupt
Wheels Acid SLX 30, 32/32 Spokes, 15x110mm/12x148mm,
Tubeless Ready
Tyre Schwalbe Nobby Nic, Performance, 2.6
Saddle Acid Venec EMTB Trail 140
Seatpost Cube Dropper Post, Handlebar Lever, Internal
Cable Routing, 31.6mm
Seatpost clamp Cube Semi-Integrated
Pedals Acid PP MTB
