Frameset
SWAT internal downtube storage
Frame - M5 Alloy chassis and rear-end, Trail Geometry, SWAT™
Door integration, head tube angle adjustment, threaded BB, internal cable
routing, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH
compatible, 145mm of travel
Seat Binder - Alloy, 38.6mm
Suspension
Rear Shock - X-Fusion 02 Pro RL, Ride Dynamics Trail Tune,
rebound adjust, lockout S1:210x52.5mm, S2-S6:210x55mm
Fork - RockShox, Psylo Silver, Motion Control Damper, 15x110
axle, 44mm offset, S1:140mm of travel, S2-S6:150mm of travel
Brakes - Rear Brake
Shimano, BR-MT420, 4-piston caliper, hydraulic disc, S1-S2:
180mm, S3-S6: 203mm
Front Brake - Shimano, BR-MT420, 4-piston caliper, hydraulic
disc, 203mm
Drivetrain
Chain - Shimano Deore, M6100, 12-speed
Crankset - Shimano Deore, M6120, 30T ring, 55mm chainline,
S1-S3:165mm, S4-S6: 170mm
Cassette - Shimano
Deore, M6100, 12spd w/Hyperglide+, 10-51t
Rear Derailleur - Shimano Deore, M6100, 12pd, Shadow Plus
Shift Levers - Shimano Deore, M6100, 12spd
Wheels & tyres
Rear Tyre - Eliminator, GRID TRAIL casing, GRIPTON® T7
compound, 2Bliss Ready, S1-S2: 27.5x2.3, S3- S6: 29x2.3"
Rear Hub - Alloy, sealed cartridge bearings, 12x148mm
thru-axle, 28h
Rims - Specialized Alloy, Tubeless Ready, 29mm internal
width, 28h, Front: 29, Rear: S1-S2: 27.5, S3- S6: 29
Front Hub - Alloy, sealed cartridge bearings, 15x110mm
thru-axle, 28h
Spokes - Stainless, 14g
Inner Tubes - Standard, Presta valve
Front Tyre - Butcher, GRID TRAIL casing, GRIPTON® T9
compound, 2Bliss Ready, 29x2.3"
Cockpit
Stem - Alloy Trail Stem, 35mm bar bore
Saddle - Bridge, Steel rails, S1-S2: 155mm, S3-S6: 143mm
Handlebars - Specialized, 6000 series alloy, 6-degree
upsweep, 8-degree backsweep. S1-S2: 780 width, 20mm rise: S3-S4: 800 width,
30mm rise: S5-S6: 800 width, 40mm rise
Grips - Specialized Trail Grips
Seat Post - TranzX Dropper, remote SLR LE lever, 34.9, S1:
125mm, S2: 150mm, S3: 170mm, S4-S6: 200mm
Weight
16.57 kg (36 lb, 8.5 oz)
Weight Size
S4
